Get the most out of your
Telematics project
Reduce your TCO in car

The first complete SCAN tool in a box !

Valisediagnostic 08c929e882ee6c722e21d355633ffc39cd97a86349964d29974ace32f185cbe4

Access exclusive data

Munic Box can be programmed to periodically scan the vehicle and retrieve valuable information which, until now, was available to just a few (i.e. car dealers, repair shops). Fault codes and prognostic data included! Munic.Box helps you keep vehicles in top-notch conditions!

Complete Scan Tool in a box

Disappointed by the limitations of the OBD standards ? Thanks to its unique and advanced OBDStacks interface, Munic.Box enables you to conduct a complete scan of virtually every ECU in any vehicle. Upon connection, Munic.Box will retrieve the Vehicle Identification Number (VIN) and synchronize this information with an online library covering almost all vehicles. Once done, Munic.Box will then upload the instruction set required to fully scan the various ECUs onto the device.

Diagnostic b923fa4fc79221f58ae02ce503d6a93b8971fe61558a83ae3e360ceab830d703

Measure & Analyze Driving Behavior like never before

Map 5cbde7fc29441d99ce8da15bd97876ca7ce769b321778f73923423aa7112fc36

Advanced inertial Navigation system

An accurate driver profiling algorithm requires high quality data from the sensors. Munic.Box features a unique and highly advanced INS engine that processes raw 3D data collected from the device’s sensors at 1kHz, eliminating spurious noise and converting the data into a normalized, calibrated stream at 15Hz aligned with the axes of the vehicle.

Detection of driving events

Thanks to a pattern detection module developed by Mobile Devices, Munic.Box accurately detects and reports harsh braking, rapid acceleration and cornering events. And since various vehicle types will require different configurations, Munic.Box offers unique customization possibilities through an innovative pattern definition script that you can write yourself or purchase from the Munic.Box store.

Boost Fuel Efficiency

Ecodriving 85207c1a4376642a8c0274b52b1b1a3ee2e6c45870c8410ed24c6a1311c775ce
1 9303d2fa57827530f09d612830928c974230ed6851126a9090ad3ce03a1c5f65

Real time engine data

Engine data can tell you a lot about a driver’s style and the efficiency at which the engine is being used. enables complete engine monitoring thanks to the information it provides you: RPM, torque, pedal position, selected gear and much more…

2 41ae3290178a6833d93723a65a33e4c017e6ca1c8d9c83cbecb16f40f2bfa452

Fuel consumption

Based on real time OBD information, provides accurate fuel consumption data which you will receive automatically at the end of each trip. In addition Munic.Box can provide accurate fuel measurement and instantaneous consumption read directly from the dashboard.

3 b9a1f6258eee96d2534da127ec54d2408d92eba3ccbe93fc9601fb0a083915b9

Over speeding

When a vehicle is speeding, fuel consumption increases dramatically . Munic.Box monitors vehicle speed and detects speeding events.

Capture Crash Data

Crash notification

Every is equipped with a crash detection algorithm that constantly runs in the background and analyzes in real time data collected by its sensors. Upon detection of a crash pattern, a 10-second buffer of 400 Hz or 1 KHz accelerometer data is stored and a notification of event is automatically sent to the server with a severity index.

Crash conditions

Crash reconstruction requires understanding the conditions surrounding a crash and accurately assessing whether to send emergency services. This can only be done through the analysis of a comprehensive set of pre and post crash data including accelerometer data and information obtained from the vehicle such as airbag deployment, ABS monitoring, seat belt, brake, driver seat sensors etc… Munic.Box will give you the tools to retrieve this data from the vehicle.

Crash 2d20da392122ecd05bee864edcfa59784237429730c8ad3b066a579b2dc17a58
